Jabsco Par-Max HD4 Heavy Duty Water Pressure Pump - 24V - 4 GPM - 60 PSI

Jabsco Par-Max HD4 Heavy Duty Water Pressure Pump — a rugged 24V system delivering reliable, high-flow water pressure for marine, RV, and other demanding applications. This model provides 4 GPM at 60 PSI, making it ideal for vessels with multiple outlets and on-demand water needs.

HD (Heavy Duty) models feature a wider diameter motor with a powder-coated shell, plus cast aluminum endbells and a lower housing to improve pressure capability and life. Available in configurations up to 6 GPM (23 LPM) and 60 PSI (4.1 BAR), these pumps deliver exceptional performance. Standard models provide good performance in an economical footprint and are available in 1-3 GPM for vessels with fewer outlets. A plastic housing protects the motors from corrosion.

Key advantages

• Co-molded diaphragm technology for long life and durability
• HD models with heavy-duty motors and cast aluminum lower housings for long life at high pressures
• Efficient and quiet operation
• Integrated, sealed pressure switch for on-demand operation
• Self-priming allows for installation versatility
• Can run dry without damage
• Quick connect ports for easy installation, servicing, and maintenance
• Vibration dampening mounting feet
• Integrated bypass module to reduce cycling and provide smoother flow
• IPX6 ingress protection
• Corrosion-protective plastic housing on standard models
• Certifications: CE, ISO8846, RCM

Specifications

• Motor design: Brushed, permanent magnet TENV
• Pumphead upper housing material: Glass fiber reinforced polypropylene
• Diaphragm: Co-molded TPV
• Check valves: EPDM
• Max inlet pressure: 30 PSI (2.1 Bar)
• Fluid temperature range: 32°F – 140°F (0°C – 60°C)
• Dry self-priming capability: 7 ft (2.13 m)
• Certifications: CE, ISO8846, RCM
• Ingress Protection: IPX6

Designed for reliability, quiet operation, and easy installation, the Jabsco Par-Max HD4 delivers consistent pressure and durability in demanding environments. Ideal for marine freshwater systems, recreational vehicles, and other mobile setups requiring dependable water delivery with minimal maintenance.
